A tough medium duty bodyThis body is available in lengths of 9' and 10'. Inside width from side to side is 84".
SIDES: One piece sides with no welded seams. 10-gauge A607 grade-50 high tensile steel with boxed top rail and fully welded boxed rear corner post. 6" side board gussets with full length rub rails, and box-type side braces.
RUB RAILS: Full length 45 degree deflector panels are an integral part of the sides.
FLOOR: 10 gauge -two piece high tensile steel floor with 2" radius corners.
FRONT WALL: 10 gauge high tensile A607 grade 50 steel. Full width integral inverted V-type horizontal bracing.
TAILGATE: 3 Panel fully boxed 10 gauge high tensile A607 grade 50 steel with boxed horizontal reinforcements and sloping lower deflector. Tailgate is 6" higher than side.
TAILGATE HARDWARE: Heavy duty: Upper is offset cast steel hinge. Lower hook is cast steel: engages tailgate pin from top. Banjo eye keeps tailgate chain in position you select.
LIGHTS & REFLECTORS: Federal 108 lights are standard, recessed for protection, rubber mounted and shock proof.
UNDERSTRUCTURE: Completely jig built with 4" structural channel crossmembers on 12" centers and 6" structural channel longitudinal. Crossmembers are gusseted and welded to longitudinals.
OPTIONS: Air tailgate latch, 36" cab shield, 8 gauge sides, 3/16" one piece floor, 6 panel tailgate, Center coal door, Grip strut walkrod, Horizontal bracing, Asphalt chute, Front corner posts, additional options available.
